List of functions: (xxxx = 125% f. s.)
Dialog item Value Description
MENU -1...9999 Primary display, e.g. the value selected in the DISP menu appears
DISP ..... Display value which should be permanently in the display:
act actually measured value
sp1 switching point SP1
sp2 switching point SP2
max maximum peak value
min minimum peak value
ACT. -1...9999 Display of actually measured value in bar
UNIT
bar
psi
psi
HPa
mbar
Fixing the unit
bar = bar The unit is shown in the display appr.
psi x = psi x 10 every 30 sec. for appr. 5 sec.
psi = psi
HPa = Hekto-Pascal
mbar = millibar
SP.1 ..... none switching output deactivated
wind window technology
stnd standard evaluation SP2
erro error output
ON-1 -1 ... xxxx Switch-on point for SP1; if the ON value is smaller than the OFF
value the switching point evaluation is falling
OFF-1 -1 ... xxxx Switch-off point for SP1
DLY1 0,0s...9,9s Switch-on / switch-off delay for SP1 in seconds
INV-1 ..... Inversion of switching output SP1
hlfs high-level-fail-save (normally open function)
Ilfs low-level-fail-save (normally closed function)
SP.2 ..... none switching output deactivated
wind window technology
stnd standard evaluation SP2
erro error output
ON-2 -1 ... xxxx Switch-on point for SP2;
if the ON value is smaller than the OFF value
the switching point evaluation is falling
OFF-2 -1 ... xxxx Switch-off point for SP2
DLY2 0,0s...9,9s Switch-on / switch-off delay for SP2 in seconds
INV-2 ----- Inversion of switching output SP2
hlfs high-level-fail-save (normally open function)
Ilfs low-level-fail-save (normally closed function)
MAX -1 ... xxxx Display of peak value „Max“ (xxxx: = max. 125 % f. s.)
CLRH ----- Delete the maximum value memory
----- no deletion
clr delete value
