J-16
J
Laser Sight Specifications
Wavelength (color): 650 nm (red)
Operating Distance:
Laser Dot: 0.6 to 12 m (2 to 40')
Laser Circle: 0.6 to 4.5 m (2 to 15')
FDA Classification: Class II
European Classification: Class 2
Beam Diameter: 5 mm
Operating Temperature:
0 to 50°C (32 to 122°F)
Specifications
Repeatability: ±(1% rdg + 1 digit)
Resolution: 1°C or 1°F (0.1°C or °F
on OS530HR)
Response Time: 250 msec
Spectral Response: 8 to 14
µ
Emissivity: 0.10 to 1.00 in
0.01 increments
Operating Ambient: 0 to 50°C
(32 to 122°F)
Power: 4 “AA” alkaline batteries (2 sets
included) or optional ac adaptor
Battery Life: 60 hr, alkaline;
10 days, lithium
Analog Output: 1 mV/°C or 1 mV/°F
Tripod Mount:
1 ⁄
4
" to 20 UNC
Display: Backlit LCD; displays current
and min or max, differential, average
temperatures simultaneously
Alarm: High alarm standard,
with audible and visual indication
RS-232: One way communication
Model No. Price Description
OS520-ADAPTOR-110V $25 110 Vac wall adaptor
OS520-ADAPTOR-220V $25 220 Vac wall adaptor
OS520-RCC 30 Hard carrying case
OM-3000-SC 15 Soft carrying case (spare)
88013K 110 Surface probe, up to 815°C (1500°F)
88001K 110 Surface probe, up to 482°C (900°F)
CAL-3-IR 125 NIST Traceable Calibration
TRIPOD 45 Lightweight tripod with carrying case
HH-DM 75 Distance measuring meter with mounting bracket
Accessories
To Order (Specify Model Number)
Model Number OS530L OS530HR OS530L-CF OS532 OS533-CF OS533RS OS534-CF OS534DL
Price $295 $345 $345 $550 $695 $650 $750 $750
Accuracy* ±1% rdg ±1% rdg ±1% rdg ±1% rdg ±1% rdg ±1% rdg ±1% rdg ±1% rdg
Range -18 to 538°C -30 to 121°C -18 to 538°C -18 to 538°C -18 to 538°C -18 to 538°C -18 to 871°C -18 to 871°C
0 to 1000°F -22 to 250°F 0 to 1000°F 0 to 1000°F 0 to 1000°F 0 to 1000°F 0 to 1600°F 0 to 1600°F
Emissivity adjustable adjustable adjustable adjustable adjustable adjustable adjustable adjustable
Backlit Dual Display std std std std std std std std
Distance to Spot Size Ratio 10:1 20:1 0.15" @ 6" 10:1 0.15" @ 6" 20:1 0.15" @ 6" 30:1
Differential Temperature std std std std std std std std
Min/Max Temperature std std std std std std std std
Average Temperature std std std std std std std std
High Alarm std std std std std std std std
Low Alarm — — — — std std std std
Audible Buzzer & Indicator std std std std std std std std
Ambient Target Temp Comp. — — — — std std std std
Analog Output 1 mV/deg 1 mV/deg 1 mV/deg 1 mV/deg 1 mV/deg 1 mV/deg 1 mV/deg 1 mV/deg
RS-232 Output — — — — std std std std
Thermocouple Input — — — std std std std std
Data Storage — — — — — — std std
Laser Sight (Built-In) dot/circle dot/circle dot dot/circle dot dot/circle dot dot/circle
Trigger Lock std std std std std std std std
Last Temperature Recall std std std std std std std std
Distance Measuring optional optional — optional — optional — optional
* or 1.7°C (3°F), whichever is greater. Model OS530HR has 0.1° display resolution.
Ordering Examples: OS532, handheld infrared thermometer with built-in dot/circle laser sighting, thermocouple input, plus OCW-3,
OMEGACARE
SM 3 -year extended warranty, $550 + 137 = $687. OS534-CF, close-focus handheld infrared thermometer with built-in laser sighting,
thermocouple input and RS-232 output, plus OCW-3 OMEGACARE SM 3-year extended warranty, $750 + 187 = $937.
MOST POPULAR MODELS HIGHLIGHTED!
Lightweight tripod
with carrying case sold
separately, $45
HH-DM distance
measuring meter
sold separately, $75
OS530E-DM Series MEGASCOPE™
Built-In Distance Measuring
Now Available!
Consult Sales and Engineering for Additional Information
at 1-800-TC-OMEGA
®
Covered by U.S and
International patents and
pending applications
PATENTED
