With a combination of powerful features, the portable and rugged OS530
Series infrared thermometers offer solutions for many non-contact temperature
measurement applications. Emissivity adjustable in 0.01 increments, the
OS530 series provides versatility when measuring a variety of surfaces.
A custom backlit LCD display provides dual digital display of both current
and max, min, diff or average temperatures simultaneously. This provides
the user with more information at a glance. Built-in laser sighting creates a
12-point circle which clearly indicates the target area being measured.
The OS530 also features a high alarm setpoint, providing both audible and
visual indication of the alarm status. The standard 1 mV per degree analog
output allows interfacing with data acquisition equipment, including chart
recorders, dataloggers and computers.
