Introduction
OMG-COMM2-EX Page 1
Introduction
Overview
The OMG-COMM2-EX provides the PC with 2 asynchronous serial ports
providing a versatile interface field selectable as RS-232 for modems, printers and
plotters, as well as RS-422/485 for industrial automation and control applications.
What’s Included
The OMG-COMM2-EX is shipped with the following items. If any of these items
are missing or damaged, contact the supplier.
•
OMG-COMM2-EX Serial I/O Adapter
•
Software
Factory Default Settings
The OMG-COMM2-EX factory default settings are as follows:
Port # Base Address IRQ Electrical Interface
Port 1 280 5 RS-422
Port 2 288 10 RS-422
To install the OMG-COMM2-EX using factory default settings, refer to
Installation on page 6.
For your reference, record installed OMG-COMM2-EX settings below:
Port # Base Address IRQ Electrical Interface
