Introduction
Views of Projector
Front-right View
1
7
6
5
4
3
8
2
3
I
TEM
L
ABEL
D
ESCRIPTION
S
EE PAGE
:
1.
Focus
Focuses the projected image
2.
Lens zoom
Enlarges the projected image
3.
Screws
Holds lamp to projector
4.
See “Top view—OSD buttons and LEDs”
5.
IR receiver
Receiver for IR signal from remote control
6.
Lens
Remove lens cap before use
7.
Lens cover
Slide across to protect lens when not in use
8.
Height-adjuster but-
ton
Push to release height adjuster
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
