Orion ED80T CF User Manual

Orion, Ed80t cf apochromatic refractor

i n s t r u c t i o n M a n u a l

IN 391 Rev. A 07/10

customer support (800) 676-1343 • E-mail: [email protected]

Corporate Offices (831) 763-7000 • 89 Hangar Way, Watsonville, CA 95076

Orion

ED80T CF

Apochromatic Refractor

#9525

Providing Exceptional Consumer Optical Products Since 1975

OrionTelescopes.com

Dew shield
(retracted)

Dovetail base
for finder

Focuser rotation
lockscrew

2" Accessory
thumbscrew

2" Diagonal

Fine focus
knob

Course
focus
knob

1/4"-20
Mounting block

Figure 1:

The 80mm ED80T CF Apochromatic Refractor optical tube.

Focuser
rotation
lockscrew
