Orion ASTROVIEW 9827 User Manual
Page 2
2
Figure 1.
The AstroView 6 EQ
Declination slow motion
control
Declination lock lever
Counterweight shaft
Large counterweight
Small counterweight
“Toe Saver”
Counterweight lock knobs
Tripod leg
Accessory tray bracket
Accessory tray
Finder scope
Finder scope bracket
Eyepiece
Focus knob
Tube rings
Optical tube
Right ascension slow-
motion control
Right ascension lock lever
Polar axis finder (covered)
Latitude scale
Latitude adjustment
T-bolts
Leg lock knob
