29. Power Cord
30. COAXIAL DIGITAL AUDIO OUT Jack
31. S-VIDEO OUT Jack
32. VIDEO OUT Jack
33. Right AUDIO OUT Jacks
34. Left AUDIO OUT Jacks
DISPLAY DISPLAYS DURING
OPERATION
LOADING THE BATTERIES
1. Open the battery compartment
cover.
2. Insert two AA batteries, with
each one oriented correctly.
3. Close the cover.
Notes
● Do not mix alkaline and manganese batteries.
● Do not mix old and new batteries.
DIGITAL AUDIO OUT
PCM / BITSTREAM AUDIO OUT VIDEO OUT S-VIDEO OUT
COAXIAL R L
1
2
29 30 31 32 33 34
 REAR VIEW 
Lit when a CD is inserted
Lit when a DVD is inserted
Displays a chapter or track number
Displays a title number
Displays the time lapse of the
current title or track
Power off
Disc setting
error
During disc
load
Tray open
Tray closed
Tray rotation
No disc inserted
During
search mode
Power on
