Onkyo ED-205 - Manual

AV Surround Processor
ED-205
AV SURROUND PROCESSOR
STANDBY/ON
STANDBY
EFFECT MODE
MASTER VOLUME
MULTI CH INPUT LINE VIDEO-1/2
ED-205
POWER
OFF ON
Instruction Manual
Thank you for purchasing the ONKYO AV Surround
Processor.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable you
to obtain optimum performance and listening enjoyment
from your new AV Surround Processor.
Please retain this manual for future reference.
Contents
Before using
Important Safeguards ........................... 2
Precautions ........................................... 3
Features ................................................ 4
Supplied accessories ............................ 4
Before using this unit ........................... 5
Operation
Using the remote controller ............... 11
Using the Surround modes ................. 12
Playing a source ................................. 14
Preparation
Connecting the amplifier and video
equipment ........................................... 6
Connecting equipment with 5.1-
channel audio output .......................... 7
Speaker placement and connection ...... 8
Connecting the z remote control
cables ................................................ 10
Connecting the power ........................ 10
A few important notes
Troubleshooting ................................. 17
Control positions and names .............. 18
Specifications ..................................... 20
