Orion AstroView 9005 User Manual
Page 2
2
Tube rings
Objective lens cell
Dew cap/lens shade
Declination lock lever
Large counterweight
Small counterweight
Counterweight lock knobs
Counterweight shaft
“Toe saver”
Tripod leg
Accessory tray attachment point
Accessory tray bracket
Accessory tray
Leg lock knob
Finder scope
Finder bracket
Focus knob
Eyepiece
Star diagonal
Right Ascension slow-motion control
Declination slow-motion control
Right Ascension lock lever
Polar axis finder scope
Latitude adjustment T-bolts
Figure 1.
The AstroView 120ST EQ Refractor
