Onkyo TX-SR8450 - Manual (Page 66)

66
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■
AM
General
■
Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Rated Output Power (FTC)
All channels: 75 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08%
100 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.1%
Rated Output Power (IEC)
7 ch
×
130 W at 6 ohms, 1 kHz, 1 ch
driven
Maximum Output Power (JEITA)
7 ch
×
160 W at 6 ohms, 1 kHz, 1 ch
driven
Dynamic Power 180 W + 180 W (3 Ω , Front)
140 W + 140 W (4 Ω , Front)
95 W + 95 W (8 Ω , Front)
THD (Total Harmonic
Distortion)
0.08% (Power Rated)
Damping Factor 60 (Front, 1kHz, 8 Ω )
Input Sensitivity and
Impedance
200 mV/ 47 k Ω (LINE)
Output Level and
Impedance
200 mV/ 470 Ω (REC OUT)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB
(Direct mode)
Tone Control ±10 dB, 80 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance North American: 6 Ω –16 Ω
Others: 4 Ω – or 6 Ω –16 Ω
Input Sensitivity/Output
Level and Impedance
1 Vp-p /75 Ω (Component and S-Video Y)
0.7 Vp-p /75 Ω (Component P B /C B , P R /C R )
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
Component Video
Frequency Response
5 Hz – 50 MHz
Tuning Frequency
Range
North American: 87.5 MHz– 107.9 MHz
Other: 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo: 17.2 dBf 2 µV (75 Ω IHF)
Mono: 11.2 dBf 1 µV (75 Ω IHF)
Signal to Noise Ratio Stereo: 70 dB (IHF-A)
Mono: 76 dB (IHF-A)
THD Stereo: 0.3% (1 kHz)
Mono: 0.2% (1 kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 40 dB (1 kHz)
Tuning Frequency
Range
North American: 530 kHz–1710 kHz
European: 522 kHz–1611 kHz
Others: 522/530 kHz–1611/1710 kHz
Usable Sensitivity 300 µV
Signal to Noise Ratio 40 dB
THD 0.7%
Power Supply North American: AC 120 V, 60 Hz
European: AC 230-240 V, 50 Hz
Others: AC 120/220-240 V, 50/60 Hz
AC 230-240 V, 50Hz
AC 220-230 V, 50/60 Hz
Power Consumption North American: 4.9 A
European: 570 W
Others: 525 W
Standby Power
Consumption
North American: 0.1 W
European: 0.2 W
Others: 0.5 W
Dimensions
(W
×
H
×
D)
435
Ч
151
Ч
377 mm
17-1/8"
Ч
5-15/16"
Ч
14-13/16"
Weight North American: 9.6 kg
21.2 lbs.
Models with voltage selector: 10.4 kg
22.9 lbs.
Others: 10.3 kg
22.7 lbs.
Component DVD, VIDEO1, VIDEO2
S-Video DVD, VIDEO1, VIDEO2
Composite DVD, VIDEO1, VIDEO2, VIDEO3
Component MONITOR
S-Video MONITOR, VIDEO1
Composite MONITOR, VIDEO1
Digital Inputs Optical: 3
Coaxial: 1
Analog Inputs DVD (MULTICHANNEL), VIDEO1,
VIDEO2, VIDEO3, TAPE, CD
Multichannel Inputs 7.1
Analog Outputs TAPE, VIDEO1
Subwoofer Pre Outputs 1
Speaker Outputs
SP A (L, R, C, SL, SR, SBL, SBR)
SP B (L, R)
Phones 1
