Programming
OMG-USB-DIO48
Page 10
Figure 7 below gives the absolute address for each bit on this device.
Bank 1 – P2
Bank 2 – P3
Addres
s
Port-Bit
Addres
s
Port-Bit
0
A1-0
24
A2-0
1
A1-1
25
A2-1
2
A1-2
26
A2-2
3
A1-3
27
A2-3
4
A1-4
28
A2-4
5
A1-5
29
A2-5
6
A1-6
30
A2-6
7
A1-7
31
A2-7
8
B1-0
32
B2-0
9
B1-1
33
B2-1
10
B1-2
34
B2-2
11
B1-3
35
B2-3
12
B1-4
36
B2-4
13
B1-5
37
B2-5
14
B1-6
38
B2-6
15
B1-7
39
B2-7
16
C1-0
40
C2-0
17
C1-1
41
C2-1
18
C1-2
42
C2-2
19
C1-3
43
C2-3
20
C1-4
44
C2-4
21
C1-5
45
C2-5
22
C1-6
46
C2-6
23
C1-7
47
C2-7
Figure 7- Absolute Bit Address (Same for any configuration)
