24
Connecting Your Components—Continued
In addition to video playback, with this hookup example, you can use the VCR’s tuner to listen to the sound of your
favorite TV programs via the AV receiver. This is useful if the TV has no audio outputs.
• With the basic connection, you can listen to the VCR/DVD recorder.
• To enjoy Dolby and DTS listening modes, use connection or . (Use and or and to listen via
speaker set B.)
Connecting a VCR or DVD Recorder for Playback
Connection TX-SR303/303E Signal flow VCR/DVD recorder
VIDEO 1 IN
⇐
Composite video output
VIDEO OUT
VIDEO 1
IN
Step 1: Video Connection
Make video connection
. A
A
VCR,
DVD recorder
A
Connection TX-SR303/303E Signal flow VCR/DVD recorder
VIDEO 1 IN L/R
⇐
Analog audio L/R output
DIGITAL IN COAXIAL
⇐
Digital coaxial output
DIGITAL IN OPTICAL
⇐
Digital optical output
OPTICAL
OPTICAL
OUT
L
R
L
R
IN
VIDEO 1
AUDIO
OUT
DIGITAL IN
COAXIAL
COAXIAL
OUT
Step 2: Audio Connection
Choose a connection type (
, , or ), and then make the connection. a b c
VCR,
DVD recorder
a
b
c
Connect one
or the other
a
b c a b a c
a
b
c
