Oreck SPEED SWEEP TEK 100 - Manual (Page 8)

Assembly Instructions
Operation
1. It is necessary for the rechargeable battery to be fully charged prior to use.
2. The charger is uniquely designed for the rechargeable Ni-MH battery, rating:
Input: 120V, 60 Hz, 50mA; Output: 9V DC, 280Ma; Class: 2
3. After inserting the plug of the charger into the electrical socket, the power light
(green) will illuminate. Insert the rechargeable battery module, this will cause
the charge indicator light (red) to blink. Battery will be fully charged after
8 hours when red light is solid (not blinking).
4. Once the battery is fully charged, it can be placed into the unit. Before doing
so, be sure to switch the power “OFF” to prevent any possible electrical
discharge.
Battery removal
Removing the rechargeable battery is done by simply pressing the battery release
button located on the side of the unit as shown below.
BATTEry rELEASE BUTTOn
7
BATTEry
CHArGEr
BATTEry
