Page 7
Assembly Instructions
Assembly of roller Brush
As is shown in the figure below, carefully insert the roller brush into the unit, making
sure to align within the specific guide slots and ensuring electric contacts are fully
aligned.
Assembly of the Handle
As shown below, pressing the handle release button will allow for the handle to be
removed from the main unit. To reinstall, simply reinsert the handle making sure
the guide slots line up.
ELECTrICAL COnTACTS
GUIDE SLOTS
HAnDLE rELEASE BUTTOn
6
