POWER
Power connection should be made to the three terminal connector as shown in figure 3. Also, make note that it is very
important that the power line inputs and the power ground are not switched. Doing so will permanently damage the
instrument. Refer to Figure 3 for proper connections. For convenience, the printed circuit board is labeled
L1 L2 GND on the under side of three terminal power connector. For instruments with the 15Vdc power option,
L1 = negative supply and L2 = positive supply.
NOTE: WHILE CONNECTING POWER TO THE UNIT, MAKE SURE THAT AC POWER LINE L1 OR
L2 IS NOT ACCIDENTALLY CONNECTED TO GROUND (GND) TERMINAL. THIS WILL RESULT IN
PERMANENT DAMAGE TO THE INSTRUMENT.
DOUBLE CHECK THE CONNECTIONS BEFORE APPLYING POWER!!
INPUT CONNECTOR PIN ASSIGNMENT
CH1
- CH1+ CH2 - CH2 + CH3 - CH3 + CH4 - CH4 + CH5 - CH5 + CH6 - CH6 + CH7 - CH7 +
Table 4. DPS3300 Series Output Connector Pin Assignments
OUT-PUT CONNECTOR PIN ASSIGNMENTS
Pin # Signal
Relay Output Open Collector
1 Channel #1 Limit Common Positive Output
2 Channel #1 Limit Normally Open/Closed* Negative Output
3 Channel #2 Limit Common Positive Output
4 Channel #2 Limit Normally Open /Closed* Negative Output
5 Channel #3 Limit Common Positive Output
6 Channel #3 Limit Normally Open/Closed* Negative Output
7 Channel #4 Limit Common Positive Output
8 Channel #4Limit Normally Open/Closed* Negative Output
9 Channel #5 Limit Common Positive Output
10 Channel #5 Limit Normally Open/Closed* Negative Output
11 Channel #6 Limit Common Positive Output
12 Channel #6 Limit Normally Open/Closed* Negative Output
13 Channel #7 Limit Common Positive Output
14 Channel #7 Limit Normally Open/Closed* Negative Output
* = Normally Open/Closed is user programmable (Look under Set-up)
NOTE: PROPER RATING, CONNECTION AND CORRECT ORIENTATION OF THE CONNECTOR IS
NECESSARY TO AVOID MALFUNCTION OR PERMANENT DAMAGE TO THE UNIT.
