Rear panel – Onkyo Network A/V Receiver HT-R690 User Manual
Page 9
9
En
DIGITAL IN COAXIAL and OPTICAL jacks
COMPONENT VIDEO IN and OUT jacks
ETHERNET port
FM ANTENNA jack and AM ANTENNA terminal
PC IN jack
HDMI IN and OUT jacks
SPEAKERS terminals
(
CENTER, FRONT, SURROUND, SURROUND
BACK or FRONT HIGH, ZONE 2)
Power cord
REMOTE CONTROL jack
Composite video and analog audio jacks
(
BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT
IN, GAME IN, TV/CD IN)
MONITOR OUT V jack
ZONE 2 LINE OUT jacks
UNIVERSAL PORT jack
SUBWOOFER PRE OUT jack
Rear Panel
See “Connecting the AV Receiver” for connection
(
