5
Precaution on use
■ Placement
• The enclosure is made of wood and therefore sensitive to extreme temperatures and humidity. Avoid placing the
unit in locations subjected to direct sunlight or in humid places such as near an air conditioner, humidifier, a
bathroom or kitchen. If you do so, damage may occur.
• Keep water and other liquids away from the unit. If water is spilled into the unit, not only the unit but also the
connected receiver may be damaged.
• Place the unit on a level and rigid surface free from vibration.
• This unit is designed to be used in the upright vertical position only. Do not use it in the horizontal or tilted position.
• If the unit is used near a turntable or CD player, howling or skipping of sound may occur. To prevent this, move the
unit away from the turntable or CD player or otherwise lower the unit’s output level.
Note:
Abnormal sound can be produced when bass-range signals are excessively boosted by using the receiver’s tone controls
or a graphic equalizer, or when a source has the bass range abnormally boosted and is played. Rattling occurs when the
signal is beyond the driver’s reproduction capacity. Although it is not a sign of damage, decrease the speaker output
level to prevent damage to the driver.
Troubleshooting
Specifications
Type Bass-reflex with built-in power amplifier
Frequency response 30 Hz-150 Hz
Output power 150 W Dynamic
Input sensitivity 220 mV
Input impedance 15 k
Ω
Woofer 200 mm cone type
Power supply AC 230-240 V, 50 Hz
Power consumption 77 W
Dimensions (W
×H×D)
235
Ч 518 Ч 411 mm
Weight 12.6 kg
Specifications and appearance are subject to change for improvement without prior notice.
Symptom Cause Remedy
The unit does not turn on • The power plug is not fully inserted. • Insert the power plug fully into the
power outlet.
No sound output • The OUTPUT LEVEL knob is set to the
MIN level.
• Pin-connector cable is disconnected at the
LINE INPUT jack.
• The input signal is so small that the unit
entered the standby state.
• Set the OUTPUT LEVEL knob
properly.
• Connect the cable to the LINE
INPUT jack.
• Increase the subwoofer output level
of the receiver slightly.
Hum noise • Pin-connector is not inserted completely.
• External leakage flux (induction noise by
TV, etc.) occurs.
• Fully insert the pin-connector.
• Set the unit away from the noise
source.
