EXTERNAL INPUT
TERMINALS
CONNECTING PLASMA DISPLAY TO AUDIO SYSTEM
NOTE
Cables shown here are not included with the plasma display.
AUDIO Signal Connection
AUDIO
2
×RCA
audio cables
R
L
TV
AUDIO IN
VIDEO
AUX
(Example: Amplifier/Receiver)
Audio output
to L/R sockets
R
L
AUDIO OUT
Connect the AUDIO OUT from the plasma display to the AUDIO IN on the amplifier/receiver.
