Connecting devices to the av input terminals, External input terminals, Video signal connection (basic signal transfer) – Sylvania SRPD442 User Manual
Page 21
21
EXTERNAL INPUT
TERMINALS
CONNECTING DEVICES TO THE AV INPUT TERMINALS
Connect the output of the device to the input terminals of plasma display as shown in the following illus-
trations.
NOTE
• You will select TV channels with the VCRs, or Cable/Satellite set top box that will be viewed on the plasma dis-
play.
• Cables shown here are not included with the plasma display.
VIDEO Signal Connection (Basic Signal Transfer)
AUDIO
S-VIDEO
2
×RCA
audio cables
Audio
OUT
Video
OUT
S Video
OUT
R
L
(DVD Player)
Example of input signal source
(VCR)
(
Cable/Sat STB)
(
Camcorder)
AUDIO
VIDEO2
S-VIDEO2
R
L
Antenna or
cable signal
Antenna, cable,
satellite signal
VIDEO1
AUDIO
S-VIDEO1
L
R
Video input to
S-VIDEO socket
Audio input to
L/R sockets
Video input to
S-VIDEO socket
Audio input to
L/R sockets
