SPECIFICATIONS
1. All channels driven, continuous 4W load 20Hz to 20kHz, < 0.05% THD, with input voltage
at 13.8VDC.
2. All channels driven, continuous 2W load 20Hz to 20kHz, < 0.1% THD, with input voltage at
13.8VDC.
Amplifier Section Front and Rear Channels Subwoofer Channel
Power Output 4W stereo (Watts)1 50 x 4 N/A
Power Output 2W stereo (Watts)2 100 x 4 N/A
Power Output 4W mono (Watts)1 200 x 2 150 x 1
Power Output 2W mono (Watts)2 N/A 300 x 1
Remote Gain No Yes
Distortion - with all channels driven < 0.1% THD+N
at rated power (20Hz to 20kHz)
Frequency Response 20Hz to 20kHz ±0.25dB
Linear Bandwidth 10Hz to 50kHz ±3dB
Signal-to-Noise Ratio at Rated Power > 100dB
Damping Factor > 200
Slew Rate > 20V per usec
RCA Input Sensitivity 200mV to 5V
Input Impedance 40kW
Fuse Type 1 x 70 Amp MAXI
Dimensions 24.4" x 10.5" x 2.3"
Weight 10.5 lbs.
Crossover Section
Low Pass Crossover 2nd Order 2nd or 4th Order
Low Pass Frequency Range 20Hz to 3kHz 20Hz to 3kHz
High Pass Filter 2nd Order 2nd Order
High Pass Frequency Range 20Hz to 3kHz 10Hz to 3kHz
INTELLi Q None 10dB boost
4 ©2003 Directed Electronics, Inc.
