4.0 HHT13 SPECIFICATIONS
Laser Specifications:
Classification: Class 2 (per IEC 60825-1 Ed 1.2 2001-8)
Complies with FDA performance standards for laser products except
for deviations pursuant to Laser Notice No. 50, dated July 26, 2001.
Maximum Laser Output: 1mW
Pulse Duration:
Continuous
Laser Wavelength: 650 nm
Beam Divergence: < 1.5 mrad
Beam Diameter: 4 x 7 mm typical at 2 meters
Laser Diode Life: 8,000 operating hours MTBF (1 year
warranty)
Non-Contact Specifications:
Ranges: RPM 5 – 200,000
RPS 0.084 – 3,333.3
RPH 300-999,990
Resolution: Fixed: 1 (10 above 99,999)
Auto-ranging: 0.001 to 1.0 (10 above 99,999)
Accuracy: ± 0.01% of reading or resolution limit
Operating Range: up to 25 feet (7.62 m) or up to 70 degrees off
perpendicular to reflective tape target
Contact Specifications using optional Remote Contact Assembly:
Range: Contact Tips: 0.5 to 20,000 RPM
10 cm / 12-inch Wheel: 0.5 to 12,000 RPM
Resolution: Fixed: 1 (10 above 99,999)
Auto-ranging: 0.001 to 1.0 (10 above 99,999)
20
8. Save and
advance
9. Exit Setup –
Ready to
measure
Measure:
Reset
Lap
Power Off
Unit will remember these settings (including lock on/off) even if turned off
and back on.
DONE, then Units
selected
Manual
Auto
Each press toggles Start and Stop
Start and Stop triggered by
Remote Optical Sensor
(HHT20-ROS)
With Timer stopped -
Resets time to 00:00.0
With Timer running -
Stops at elapsed time to date.
To continue, press again.
OR
9.2 TIMER Operation
Automatic after 90 seconds
if unit not Locked on OR
