■ BE SURE TO CHECK THE FOLLOWING BEFORE USING YOUR STICK EDGER
Item to be checked Response
1 Edging mechanism • See if attachment is loose • Tighten screws and bolts
• Check if edges of blades are dull • Sharpen or replace blades
2 Throttle • Stiff and difficult to move • Repair or replace
3 Throttle wire • Too loose, too tight • Adjust
• Stiff and difficult to move • Repair or replace
4 Engine attachment • See if fittings are loose • Tighten fittings
5 Fuel tank • See if attachment is loose • Tighten screws and bolts
• See if fuel pipe is damaged • Replace
• See if cap packing is damaged • Replace
6 Muffler • See if attachment is loose • Tighten screws and bolts
■ REGULAR MAINTENANCE INSPECTION
Check the stick edger for damage or problems at the intervals shown below.
Maintenance
• Always be sure to stop the engine before inspecting the stick edger for problems or
performing maintenance.
• Never alter the stick edger or take the engine apart.
• When replacing parts, always be sure to use only RedMax products or products which
have been certified by RedMax for use with the RedMax stick edger.
• Things to check before using stick edger
WARNING
Interval (number of hours)
Item to be checked 20 25 50 100 Comments
Engine
Remove grit from cylinder fins
√
Clean air filter element
√
Clean and adjust spark plugs
√
distance of 0.25" (0.65mm)
Clean fuel tank
√
Tighten cylinder bolts
√
Tighten engine fittings
√
Decarbonize muffler
√
Main body
Lubricate gear case
√
Remove grit from clutch drums
√
