v
Table of Contents
Section 1 General Description
1.1 Introduction ......................................................................... 1-1
1.2 Equipment Features ............................................................. 1-1
1.3 Minimum Function Handset /
Full Function Handset Options ............................................ 1-2
Section 2 Installation
2.1 Unpacking and Inspection ................................................... 2-1
2.2 Equipment Supplied ............................................................. 2-1
2.2.1
Optional Accessories .............................................. 2-1
2.3 Planning the Installation ...................................................... 2-2
2.3.1
Typical Mounting Methods .................................... 2-2
2.3.2 Flush Mounting ...................................................... 2-3
2.4 Electrical Connections ......................................................... 2-6
2.4.1
DC Power and External Speaker Connections ...... 2-6
2.4.2 External Speaker Connections ............................... 2-7
2.4.3 NMEA Data ........................................................... 2-8
2.4.4 Antenna Connections ............................................. 2-8
2.4.5 Antenna Mounting Suggestions ............................. 2-9
2.4.6 Grounding .............................................................. 2-9
Section 3 Operation with Minimum Function Handset
3.1 Introduction ......................................................................... 3-1
3.1.1
DSC and NMEA Operation ................................... 3-1
3.2 Minimum / Full Function Handset Priority ........................... 3-1
3.3 Handset Connections ............................................................. 3-2
3.4 Control and LCD Display .................................................... 3-3
3.4.1
Controls .................................................................. 3-3
3.4.2 LCD Display .......................................................... 3-6
3.5 Operating Procedures .......................................................... 3-8
3.5.1
Turning the Power On ............................................ 3-8
3.5.2 Setting the Squelch ................................................. 3-8
3.5.3 Setting the Volume ................................................. 3-8
3.5.4 Setting the Power Output ....................................... 3-8
3.5.5 Setting the Channel ................................................ 3-9
3.5.6 Selecting the Private Channel ................................ 3-9
3.5.7 Setting the Frequency Mode ................................ 3-10
3.5.8 Transmitting ......................................................... 3-10
3.5.9 Selecting a Weather Channel ................................ 3-11
