1 • UNDERSTANDING YOUR STEAM GENERATOR

1.

“Precision Steam Jet” nozzle
(depending on the model)

2.

“Precision Steam Jet” button
(depending on the model)

3.

Humid steam button
(depending on the model)

4.

Steam control button

5.

Temperature control dial for iron soleplate

6.

Iron temperature control light

7.

Steam generator boiler (in the base unit)

8.

Cord fastener

9.

Handles for removing and replacing
the water tank

10. Removable water tank
11. Removable water tank filler cover
12. Iron rest
13. Boiler rinse plug (under boiler cap)
14. Control panel
15. Power cord storage space
16. Power cord reel button
17. Illuminated on / off switch
18. Iron-base steam power cord

Control panel

GB

“Restart” button

Green “steam
ready” light

Steam output control dial

Orange “boiler rinse” light

Red “removable water tank
empty” light

1

2

3

4

5

6

14

11

10

7

9

15

16

8

12

13

17

18
