HSG2004
Rev.4.00 Jun 21, 2006 page 10 of 12
S parameter
(V
CE
= 3.3 V, I
C
= 30 mA, Zo = 50
Ω
)
S11 S21 S12 S22
f (MHz)
MAG ANG (deg.) MAG ANG (deg.) MAG ANG (deg.) MAG ANG (deg.)
100 0.674 -60.3 48.82 147.33 0.0124 106.4 0.755 -22.6
200 0.708 -53.6 40.51 141.98 0.0146 57.5 0.814 -53.5
300 0.668 -81.6 36.68 128.82 0.0189 39.9 0.690 -70.4
400 0.646 -104.3 33.30 117.87 0.0211 42.3 0.598 -83.9
500 0.637 -121.1 29.33 109.63 0.0216 34.1 0.544 -94.1
600 0.638 -134.3 26.04 102.93 0.0229 32.8 0.506 -102.0
700 0.640 -143.1 23.01 97.82 0.0234 31.7 0.480 -108.7
800 0.639 -150.2 20.48 93.51 0.0239 29.8 0.460 -114.2
900 0.639 -156.1 18.38 89.85 0.0244 30.0 0.448 -119.1
1000 0.639 -161.2 16.56 86.63 0.0247 28.7 0.436 -123.2
1100 0.643 -165.7 15.11 83.71 0.0248 29.6 0.431 -126.6
1200 0.647 -169.5 13.85 80.95 0.0252 27.6 0.426 -129.5
1300 0.648 -172.8 12.80 78.44 0.0259 30.7 0.424 -132.0
1400 0.649 -175.9 11.87 76.09 0.0258 30.7 0.422 -134.3
1500 0.650 -178.9 11.05 73.89 0.0269 31.0 0.422 -136.4
1600 0.653 178.2 10.31 71.81 0.0273 32.5 0.423 -138.2
1700 0.658 175.8 9.66 69.89 0.0276 31.8 0.424 -139.8
1800 0.663 173.7 9.08 67.99 0.0281 33.4 0.426 -141.2
1900 0.665 171.7 8.58 66.10 0.0288 34.3 0.428 -142.5
2000 0.667 169.5 8.14 64.14 0.0294 35.0 0.431 -143.6
2100 0.667 167.3 7.71 62.39 0.0297 35.5 0.434 -144.8
2200 0.671 165.1 7.33 60.67 0.0305 35.8 0.437 -145.7
2300 0.676 163.3 6.97 59.20 0.0311 36.7 0.440 -146.7
2400 0.682 161.6 6.66 57.56 0.0318 37.6 0.443 -147.6
2500 0.685 160.1 6.36 55.90 0.0322 37.5 0.447 -148.4
2600 0.685 158.4 6.10 54.14 0.0337 39.1 0.450 -149.2
2700 0.687 156.5 5.85 52.44 0.0342 38.8 0.453 -149.8
2800 0.688 154.7 5.61 50.90 0.0348 39.2 0.456 -150.6
2900 0.692 153.1 5.39 49.52 0.0355 39.3 0.459 -151.2
3000 0.696 151.6 5.19 48.15 0.0361 39.5 0.462 -151.8
3200 0.701 148.7 4.84 44.97 0.0380 40.5 0.467 -153.0
3400 0.702 145.2 4.51 41.72 0.0397 40.5 0.472 -154.2
3600 0.708 142.3 4.22 39.02 0.0414 40.1 0.476 -155.6
3800 0.710 139.2 3.98 35.99 0.0437 41.0 0.479 -156.9
4000 0.714 135.5 3.75 32.71 0.0458 40.5 0.483 -158.5
4200 0.722 132.4 3.54 29.88 0.0477 39.9 0.484 -160.3
4400 0.724 129.4 3.35 26.99 0.0490 38.8 0.487 -162.2
4600 0.729 125.5 3.17 23.61 0.0509 38.5 0.489 -164.4
4800 0.740 122.4 3.01 20.69 0.0530 37.5 0.493 -166.7
5000 0.746 119.5 2.86 17.76 0.0554 36.7 0.497 -169.1
5200 0.752 115.9 2.71 14.45 0.0573 35.6 0.502 -171.7
5400 0.764 113.1 2.57 11.42 0.0592 33.8 0.509 -174.6
5600 0.773 110.4 2.45 8.38 0.0614 31.9 0.516 -177.5
5800 0.778 107.0 2.32 5.20 0.0623 30.6 0.524 179.6
6000 0.789 104.5 2.19 2.09 0.0639 28.1 0.534 176.6
