3 RF-NBCAM
• The Web camera has obvious signs of breakage.
• The Web camera is not working correctly or you can’t get it to work
according to this User Manual.
Web camera components
Item Description Function
1 Snapshot button Use to capture still images.
2 LED indicator Turns on when the Web camera is connected.
3 Lens Provides the image to the Web camera.
4 Microphone Provides sound reception for the Web camera.
5 Removable base The base can be removed so you can clip the camera to your
notebook computer.
1
2
3
4
5
