S
E L E C T I N G T H E
XC
A R D S
– 7 –
Punch 3x
100 Hz
100 Hz
Output
Output
100 Hz
100 Hz
100 Hz
Blank
Rear Output
Dual Filtered
Non-Faded Output
Front Output
Punch 2x
The Punch 2x is shipped with 100Hz cards. The 3x is shipped with
100Hz and blank programmable cards and the 5x is shipped with
100Hz, 6.5kHz and blank programmable cards. The following cards
are available factory built from your Authorized Rockford Fosgate
Dealer.
XM50 50Hz
XM70 70Hz
XM100 100Hz
XM150 150Hz
XM200 200Hz
Each card can be used for high-pass, low-pass or full range operation.
The mode of operation is determined by the orientation of the XCard
in its socket. These same XCards are used in other Rockford Fosgate
products.
The following illustrations show the XCards shipped in the Punch 2x,
3x and 5x. As configured, out of the box, each card is set for full range
operation.
XM275 275Hz
XM400 400Hz
XM4.5k 4.5kHz
XM6.5k 6.5kHz
