8 — English
AssEMbly
UNpACkINg
This product requires assembly.

Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
 Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
 Do not discard the packing material until you have carefully
inspected and satisfactorily operated the product.
 If any parts are damaged or missing, please call
1-800-860-4050 for assistance.
pACkINg lIsT
String Trimmer
Grass Deflector Assembly with Screw
Front Handle Assembly
Operator’s Manual
WARNINg:
If any parts are damaged or missing do not operate
this product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
WARNINg:
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible serious
personal injury.
WARNINg:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
product when assembling parts.
Fig.
GRass
DEflEctoR
slIDE
oVER HEaD
aND
tURN
coUNtERclockwIsE
Fig. 3
scREw
scREw
HolE
ATTAChINg gRAss DEFlECToR
See Figure 2 - 3.
WARNINg:
The string cutting blade on the grass deflector is sharp.
Avoid contact with the blade. Failure to avoid contact can
result in serious personal injury.
 Remove supplied screw with a phillips screwdriver
from the trimmer head.
 Fit the grass deflector into the slots on trimmer head.
 Turn counterclockwise to lock grass deflector into
place.
 Line up the screw hole in the grass deflector with the
center hole in the trimmer head.
 Install supplied screw and tighten by turning clockwise
with a phillips screwdriver.
