Piping diagrams – Raypak 0180B Type H User Manual
Page 17
17
Air
Scoop
Air Vent
Diaphragm
Expansion Tank
Feed
Valve
Pipe Pressure
Relief Valve
to Drain
Cold Water
Inlet
Heating Units
Fig. 15: Single-Zone Piping
Air
Scoop
Air Vent
Diaphragm
Expansion Tank
Feed
Valve
Pipe Pressure
Relief Valve
to Drain
Cold Water
Inlet
Heating Units
Circulators
12” Max.
Fig. 16: Multiple Zones with Circulators
Piping Diagrams
