If you need any further advice, please
call our Technical Helpline on
0181 758 0338 (Mon-Fri)
General
Do not allow this unit to be exposed to water or steam. Do not leave the unit
where excessive heat could cause damage. It is recommended that the FM
band be used wherever possible as better results in terms of quality and
freedom from interference will usually be obtained than on the MW or LW
bands.
Mains supply
The CD9909 will operate from a supply of AC 230 volts, 50Hz only.
For your convenience this product is supplied with a plug which is fitted with
a fuse of the appropriate rating. If the plug supplied is not suitable for your
socket outlet, it should be removed by unscrewing the plug top, the terminal
screws, and removing the cable.
The correct style of plug to suit your household together with a correctly rated
fuse should be fitted.
IF IN DOUBT - CONSULT A QUALIFIED ELECTRICIAN
IMPORTANT. DO NOT make any connection to the larger terminal which is
marked with the letter E or by the safety earth symbol
or coloured Green
or Green-and-yellow.
The wires in the mains lead are coloured in accordance with the following
codes :-
BLUE - NEUTRAL BROWN - LIVE
As these colours may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire coloured BLUE must be connected to the terminal marked N or
coloured BLACK.
The wire coloured BROWN must be connected to the terminal marked L or
coloured RED.
Fuse
This apparatus must be protected by a 3A fuse (BS1362) in a 13A plug
(BS1363). If another type of plug is used a 5A fuse should be fitted in the plug,
adaptor or distribution board.
IF IN DOUBT - CONSULT A QUALIFIED ELECTRICIAN.
Batteries
Remove the battery cover on the rear of the unit by pushing the catches in the
direction of the arrows. Insert eight IEC size LR20 batteries (D size) into the
compartment. Take care to ensure all batteries are inserted with the correct
polarity as shown inside the battery compartment. Replace the battery cover.
Reduced power, distortion, and a 'stuttering' sound are all signs that the
batteries may need replacing.
We would recommend for economy, that the CD9909 is used on the
mains whenever possible with battery operation for occasional or stand-
by use only.
Automatic Mains/Battery switching
To change from battery to mains operation, simply plug the mains lead into
the mains input socket on the rear of the unit. The batteries will be
automatically disconnected. It does not matter which way round the plug is
inserted but make sure it is fully pushed home. The other end should be
plugged into a domestic supply socket.
