Out of Warranty
In the event your product requires repair after the limited warranty period has expired, please
contact our Customer Support Center at
1-800-506-5746, 1-877-252-6873 or
www.RCAav.com
Hours: Monday–Thursday: 9am–7pm, Friday: 9am–5pm, Saturday: 9am–NOON Eastern
time.
Important:
You are responsible for any transportation, shipping or insurance relative to the return of product
to our Product Returns Center.
All warranties implied by state law, including the implied warranties of merchantability and fitness for a
particular purpose, are expressly limited to the duration of the limited warranties set forth above. With the
exception of any warranties implied by state law as hereby limited, the foregoing warranty is exclusive and
in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller
with respect to the repair or replacement of any parts. In no event shall AVC be liable for consequential
or incidental damages.
No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of
these warranties in any manner whatsoever. The time within action must be commenced to enforce any
obligation of AVC arising under the warranty or under any statute, or law of the United States or Canada
or any state thereof, is hereby limited to one year from the date of purchase. This limitation does not apply
to implied warranties arising under state law.
This warranty gives you specific legal rights and you may also have other rights, which may vary, from
state to state. Some states do not allow limitation on how long an implied warranty lasts, when an action
may be brought, or the exclusion or limitation of incidental or consequential damages, so the above
provisions may not apply to you.
For more information on other products and services, please visit our web site at
www.RCAav.com
Important: Also keep your “Bill of Sale” as proof of purchase.
Model no. ................................................................................ Product name ....................................................................
Type of set. ........................................................................................................................................................................................
Serial no. ................................................................................. Invoice no. ............................................................................
Date purchased .................................................................... Dealer name .......................................................................
FOR SERVICE AND REPAIR, PLEASE VISIT
www.RCAav.com
Specifications and external appearance are subject to change without notice.
© 2009 AVC MULTIMEDIA
Cleaning
• Use a soft, dry, clean cloth. Regularly dust the
vents at the back or sides.
• Using solvents, abrasive or alcohol-based prod-
ucts risks damaging the unit.
• If an object or liquid enters inside the unit, un-
plug it immediately and have it checked by an
authorized servicer or service center.
Handling and Caring for Discs
• Handle your discs with care. Hold the disc with
your fingers at the edges or through the hole.
• Insert the disc with the label facing up (for a
single-sided disc).
• Place the disc properly into the tray in the allot-
ted holder.
Compatible Formats
In order to ensure playback, discs must conform
with DVD or CD standards. This unit may not play
some recordings or files due to differences in
recording formats, software used and disc types.
DVD-Video
Digital video discs - 12 cm, single or double sided,
single or dual layer. DVDs are high density optical
discs on which high quality picture and audio are
recorded by means of digital signals.
DVD-R, DVD-RW, DVD+R, DVD+RW
Most DVD-R and DVD+R (one recording
only), DVD-RW and DVD+RW discs
(rewritable), depending on the DVD
writer and discs used. Recordings using
DVD-R and DVD-RW discs must be made
in Video DVD mode. Recordings using
DVD+RW discs must be made in accordance with
the specifications for DVD+RW discs with a 4.7 GB
capacity.
Sleep
1. Press INFO button twice for CD and three times
for DVD. Select Sleep icon with the left/right
arrow buttons.
2. Select one of the available options using the OK
button : Off, 30, 60, 90 or 120 minutes.
Introscan (CD)
This option plays the first ten seconds of each
track on a CD.
1. Press the INFO button twice, then select the Play
mode icon with the left/right arrow buttons.
2. Press the up/down arrow buttons to select the
Intro option and press OK to start Introscan.
3. Press STOP to stop Introscan, and press PLAY to
resume normal playback.
Bookmark (DVD and Audio CD)
1. Press INFO twice for CD and three times for
DVD. Select the Bookmark icon with the left/
right arrow buttons, and press OK. A menu is
displayed with five bookmarks.
2. The first bookmark space is highlighted. Press
OK to set the bookmark. The bookmark is saved
and is indicated by the number 1.
Use left/right arrow and OK buttons, you can
set up to five bookmarks on a disc.
3. To start playback from a bookmark, press the
PLAY button on the remote control.
4. To delete a bookmark, highlight it and press
CLEAR.
The Info Menu
Printed in China
811-831691W010
Troubleshooting Additional Information Additional Information
The Setup Menu
Radio
Play Mode (All Discs Except Jpeg)
1. While the disc is playing, press the INFO button
twice for CD and three times for DVD.
2. Select the Play Mode icon using the left/ right
arrow buttons.
3. Use the up/down arrow buttons to select an
option.
• DVD play modes: standard, program, A-B
repeat, title repeat, chapter repeat. Program
play mode is only available if a program list
has been created (see below). Repeat mode is
only available with discs that display elapsed
time and remaining time. To repeat a sequence
between points A and B, choose the A-B repeat
option, and then follow the instructions for
entering the two points.
• Audio CD play modes: standard, introscan,
random, program, repeat A-B, repeat disc,
repeat track.
4. To stop repeat playback, select the Play Mode
icon and use the up/down arrow buttons to
choose the Standard option, and press OK
button.
Creating a Program List for Program
Play Mode (Audio CDs and DVD Discs)
To use program play mode, you must first create
a program list.
1. To create a program list, press the INFO button
twice for CD and three times for DVD. Highlight
the Play Mode option and press the up arrow to
select the Program option.
2. Press OK. The Program screen is displayed.
3. The first spot in the list is highlighted. Use the
number buttons on the remote control to enter
a track or title/chapter number.
4. Use the arrow buttons to move to the next spot
in the list. Enter the next track or title/chapter
number.
5. Continue entering tracks or titles/chapters until
you have completed your list.
6. Highlight the Play option at the bottom of the
screen and press OK or press PLAY to start play-
back. The program list will play in the order you
programmed it.
Press SETUP to bring up the main menu. There are
four options in the main setup menu: General
Setup, Language Setup, Audio Setup and Video
Setup. Press SETUP if you want to exit the main
menu.
General Setup
1. Select the General Setup icon in the main menu
using the left/right arrow buttons.
2. Select one of the options using the up/down
arrow buttons. And press the right arrow but-
ton to move to the option’s choices.
3. Use the up/down arrow buttons to highlight
your preferred choice and press OK.
Video
Progressive Scan Output provides higher quality
video. Turn on Progressive Scan if you’re using the
Component Video jacks of the unit to connect a
TV or monitor compatible with a progressive scan
signal.
Select P-Scan YPbPr and press OK to activate
Progressive Scan.
HDMI Setup
This lets you select the resolution of the player’s
output according to the connected TV.
• Supported HD mode: 480p, 720p, 1080i and
1080p.
TV Type
Depending on the format of the DVD disc, you
can choose the picture format (aspect ratio) best
suited to the format of your TV screen:
• 4:3 PS: reproduces a 4:3 picture without
distortion.
• 4:3 LB: gives best reproduction of pictures
recorded in this format (i.e. with horizontal
bands at the top and bottom of the screen) or
in 16:9.
• 16:9 (windscreen): reproduces 16:9 format films
in full on a 16x9 screen.
Default
This option allows you to return the unit’s settings
to the original factory settings. Any changes you
have made to the unit’s settings will be reverted
back to the original settings.
Subtitles
Select the subtitle language using up/down arrow
buttons and press OK.
To change the language of the subtitles during
playback, press INFO twice for DVD and use the
left/right arrow buttons to highlight the Subtitle
icon. Press the up/down arrow buttons or the
SUBTITLE button on the remote control to select
a subtitle language.
Disc Menu
To change the language of the disc menus, select
the language using the up/down arrow buttons
and press OK.
The language you select will only be displayed if
the disc is programmed with that language.
Audio Setup
You can adapt your unit to other equipment and
access specific functions with the Audio Setup
menu.
1. Select the Audio Setup icon in the main menu
using the left/right arrow buttons.
2. Select an option using the up/down arrow but-
tons. Press OK button to move to the option’s
choices.
Audio CDs
Audio CDs (12 cm).
CD-R, CD-RW
Most CD-R (one recording only) and CD-RW discs
(rewritable).
CD-Rs written during a multisession recording can
be played, provided that the session has ended
before the disc is played (depending on the write
software).
However, depending on the condition of the
CD-writer, computer and the disc used, you may
find that not all discs will play. When playing a
CD-R disc, it is normal for the unit to take up to
60 seconds to recognize the disc before starting
to play.
If the disc is not recognized after a period of 120
seconds, remove the disc, and insert it again.
• Do not use its full capacity.
• CD-Rs should be preferably used instead of
CD-RWs (rewritable CDs) as, in certain cases,
CD-RW playback may be faulty.
• Use reliable, good-quality CD write software.
• Close all other applications on the computer to
ensure reliable CD-R disc recording.
Jpeg Files
CD-R and CD-RW with jpeg files. Certain jpeg files,
including progressive jpeg files, cannot be read by
this unit.
The total number of files and folders on the disc
should be less than 650. Make sure that files have
the “.jpg” extension. Files without the “.jpg” exten-
sion will not be able to be read by the unit --- even
thought the files are shown as jpeg images on
your computer.
Sound Enhancement Systems
This receiver is equipped with several built-in
sound enhancement systems.
Technical Specifications:
Amplifier Section:
RMS Output Power: Dolby Digital Mode with 10%
Total Harmonic Distortion
Rear Channels: 40 Watts/channel (1kH, 4Ω)
Front Channel: 40 Watts per channel
(1kHz, 4Ω )
Center Channel: 40 Watts per channel
(1kHz, 4Ω )
Subwoofer Channel: 50 Watts (100Hz, 3Ω)
Total RMS Output Power, Dolby Digital mode:
250 Watts
Muting Attenuation: 70 dB
Frequency Response: 200Hz – 20KHz/3dB, 1KHz
ref.
Subwoofer Frequency Response: 20Hz – 200Hz/-
3dB, 100Hz ref.
Signal to Noise Ratio: 70 dB (Dolby Digital)
AM Tuner Section:
Frequency Response: 2kHz +/-3dB, 400Hz ref.
Usable Sensitivity: 3000uV/m @ S/N 20dB
Signal to Noise: 38dB
IF Rejection: 35dB
FM Tuner Section:
Frequency Response: 15kHz +/-3dB, 1kHz ref.
Quieting: 24dB
Signal to Noise: 62dB(stereo) / 65dB(mono)
IF Rejection: 70dB
Dimensions (H x W x D mm) :
Unit: 67 x 430 x 243
Front Speakers: 112 x 88.8 x 90
Center Speaker: 112 x 88.8 x 90
Rear Speakers: 112 x 88.8 x 90
Subwoofer: 307 x 145 x 253
Dolby Digital
The Dolby Digital mode lets you enjoy full digital
surround from software processed in the Dolby
Digital format. Dolby Digital provides better
sound quality and a more powerful presence
than conventional Dolby Surround. This unit is
equipped with Dolby Digital 5.1 channel so that
you can enjoy enhanced full digital surround
sound. Different from Dolby ProLogic in that only
four channels (Front Left, Front Right, Center and
Rear) are used, the new system provides stereo
separation of the rear speakers (Rear-Right, Rear-
Left). Adding the subwoofer channel to the 5
channels for bass sounds (counted as 0.1 channel)
results in 5.1 channels (or 6 Channels) that bring
you the most sophisticated Dolby Digital sound
enjoyment.
Manufactured under license
from Dolby Laboratories.
”Dolby” and the double-D
symbol are trademarks of
Dolby Laboratories.
DVD+Rewritable
IMPORTANT!
Once Progressive Scan has been activated,
an image will only be visible on a progressive
scan TV or monitor. If you choose this option
and you don’t have a progressive scan TV or
monitor, you may get a picture with incorrect
color or no color.
Notes:
• If the selected language is not available
on a disc, the disc’s language will be used
instead.
• If the language chosen is available, it
is automatically selected when you
display the subtitles or press SUBTITLE
on the remote control. Otherwise, the
subtitle language indicated on the disc is
selected.
Note:
This function is only available with discs
whose elapsed time or remaining time
appears in the Info menu.
Tips:
• When a strong FM stereo broadcasts is
tuned, ST is displayed.
• When you manually tune into a weak
FM station, press AUDIO on remote
control to switch from Stereo to Mono
mode. This will reduce the background
noise.
• If there is any interference, change the
antenna’s position until ideal sound
reception is obtained. TV and other
electronic devices could be the cause
of interference, so try to position the
antenna away from them.
• A weak signal can affect the “Automatic
preset programming” function’s
efficiency. Adjust the antenna for
better reception and a more efficient
search.
Language Setup
With this menu, you can set the language for unit
menus, audio, subtitles and the disc menus.
If you chose “English” during initial set-up, any
menus generated by the disc are in English, and
so is the language of the dialogs (if this language
is available on the disc).
1. Select the Language Setup icon in the main
menu using the left/right arrow buttons.
2. Select one of the options using the up/down
arrow buttons.
3. Press the right arrow button to move to the lan-
guage choices.
4. Use the up/down arrow buttons to highlight
the language of your choice and press OK.
Player Menu
Select the language of player menus and press OK.
Audio
Select the audio language using up/down arrow
buttons and press OK.
To change the Audio language during playback,
press INFO twice for DVD and use the left/right
arrow buttons to highlight the Audio icon. Press
the up/down arrow buttons or AUDIO on the
remote control to select audio language.
iPod is a trademark of Apple Computer, Inc.,
registered in the U.S. and other countries.
Compatible iPod Types:
• iPod nano (1st generation) 1GB, 2GB, 4GB
• iPod nano (2nd generation) 2GB, 4GB, 8GB
• iPod nano 3rd generation (video) 4GB, 8GB
• iPod nano 4rd generation (video) 8GB, 16GB
• iPod 5th generation (video) 30GB, 60GB, 80GB
• iPod classic 80GB, 120GB, 160GB
• iPod touch (1st generation) 8GB, 16GB, 32GB
• iPod touch (2nd generation) 8GB, 16GB, 32GB
Note: Also supports iPhone when iPhone is set to
“airplane mode”.
Using an Adaptor to Connecting Your
iPod
1. Open the iPod docking compartment.
2. Choose the iPod Dock Adaptor that fits your
iPod (Dock adaptors are not included with this
product, please use the one that was included
with your iPod.).
iPod Dock Adaptor (not included)
3. Insert your iPod Dock Adaptor into the dock
until it sits firmly in place.
4. Turn on the unit, press the DVD/iPod button to
select iPOD mode. Your iPod will be connected
automatically, following screen appears.
Home Docking system for iPod
Welcome
Music
Photos
Videos
Settings
4. Press the RETURN button to go back to the previ-
ous menu.
Playing Photos
1. In iPod Home menu, use the
, button to
select Photos and press the OK button.
“Please Navigate directly on your iPod” will
appear on the screen.
2. Use the , and OK buttons to navigate the
iPod menu lists and select a photo, press
PLAY button to begin playback.
• Press the PAUSE button to pause playback,
press the PLAY button again to resume
playback.
• Press the / button to skip to the previous /
next photo.
3. Press the RETURN button to go back to the
previous menu.
Using an iPod Touch (e.g. 1st
generation) to View Photos
1. In iPod Home menu, use the
, button to
select Photos and press the OK button. “Please
Navigate directly on your iPod” will appear on
the screen.
2. Touch the “Photos” selection on iPod panel,
then select the photo your prefer.
AUDIO IN / AUX IN
TV, VCR, SAT/Cable Box or portable audio players
can be connected to AUX input jacks at the back
of the unit or AUDIO IN at the front panel so that
sound from the auxiliary component or the audio
players comes into the unit and out through the
speakers.
Connecting Auxiliary Components
Refer to “Connecting AUDIO from external sources
such as TV” for details on connecting the auxiliary
components to the unit.
Selecting AUDIO IN / AUX IN Mode
Press either SOURCE on the main unit or AUDIO
/AUX on the remote control to select AUX IN or
AUDIO IN mode.
Sound Output in Aux-In Mode
• You may change the surround setting by
pressing SURROUND to select between 5.1 ch
and stereo modes.
• If the auxiliary audio signal is mono, there will
be no output from some speakers in 5.1CH
mode.
Displaying Jpeg Files
Jpeg files are image files. Make sure that they have
a resolution of less than 2 megapixels.
1. Open the disc tray.
2. Place the disc with the printed side facing up
and close the disc tray. The folders on the disc
will be listed in numerical order on the left side
of the screen. When you highlight a folder, then
press OK button. The list of pictures in the folder
are listed in numerical order on the right side of
the screen.
3. Select a folder using the up/down arrow
buttons on the remote control.
4. Press the right arrow button to move to the file
list on the right side of the screen. Use the up/
down arrow buttons to select a file. Press PLAY
to start picture slideshow.
• jpeg file: the unit starts the slide show with the
jpeg file you have selected, then displays all the
jpeg files in the same folder, then all the jpeg
files in the subfolders located in the same fold-
er. You can set the amount of time a picture re-
mains on the screen in the Video Setup menu.
During the slide show you can use the left/right
arrow buttons to rotate the picture, the up arrow
button to rotate the image vertically, the down ar-
row button to rotate the image horizontally. Use
the ZOOM button to magnify the picture. Use the
CH–/ button to go back to the previous picture
or the CH+/ button to go to the next one, and
the STOP or RETURN button to interrupt the slide
show and display the disc’s contents.
Note:
• The time taken for the contents of the
disc to be displayed varies according
to the size and number of jpeg files on
the disc. If nothing is displayed after a
few minutes, the file sizes may be too
large. Reduce the files’ resolution and
write another disc.
• Before inserting a disc, make sure it is
compatible with the unit.
• During picture slideshow, you can not
zoom out a picture unless HDMI Setup
is set to 480p.
iPod iPod iPod
Audio (DVD)
Some discs have several audio tracks used for
different languages or different audio formats.
To change the language or audio format during
playback, you can press the AUDIO button on the
remote control repeatedly to select your preferred
choice; or follow the below steps:
1. Press the INFO button twice.
2. Use the left/right arrow buttons to select the
Audio icon.
3. Choose a language or an audio format with the
up/down arrow buttons.
This option is only available if the disc offers
dialog languages or audio formats. When you
change the dialog language using the Info menu,
it only changes the dialog language of the disc
being played. When you eject the disc or switch
off the unit, the language will revert to the one
you selected in the language Setup menu.
Subtitles (DVD)
Subtitles are turned off by default. Press the
SUBTITLE button on the remote control repeatedly
during playback to select a preferred subtitle
option; or follow the below steps:
1. While the disc is playing, press INFO twice, then
select the Subtitles icon using the left/right
arrow buttons.
2. Select a language using the up/down arrow
buttons.
3. To turn subtitles off, select the Off option.
When you change the language of the subtitles
using the Info menu, it only applies to the disc
currently being played. When you eject the disc
and switch off the unit, the subtitles will default
to the subtitle language you selected in the
Languages menu.
This function may not be available on all discs.
Camera Angle (DVD)
Some discs offer different camera angles
for specific scenes. To change the camera angle,
press the ANGLE button on the remote control
repeatedly; alternatively, you can press the INFO
button twice and select the Camera angle icon
with the left/right arrow buttons, and then choose
the angle with the up/down arrow buttons.
If the disc was recorded using a single camera
angle, this function is not available.
The unit has a built-in tuner that allows for FM ra-
dio function. The AM loop antenna allows for AM
radio function.
Manual Tuning
1. Connect the FM antenna and the AM loop an-
tenna at the back of the unit.
2. Press TUNER.
3. Tune a station by pressing TUNER+/-repeatedly
until the desired station is found. Alternatively,
you can press and hold the same buttons down
for about one second to activate the automatic
search function. In this mode the unit will auto-
matically tune frequencies until it finds a station.
4. Repeat step 3 to tune to another radio station.
5. Press TUNER to toggle between FM and AM.
Storing Radio Stations
The unit can store up to 60 radio stations (AM/FM
each 30 radio stations )in its memory. You can en-
ter every single radio station yourself or the unit
can store all available radio stations automatically
in ascending order.
Automatic Preset Programming
1. Press TUNER to enter the Tuner mode.
2. Press and hold TUNER for two seconds to start
automatic preset programming.
3. Radio frequencies will be browsed and radio
stations stored automatically. When all the avail-
able radio stations are stored or all 30 memory
locations are full, the auto preset programming
function will stop.
Manual Preset
1. Tune to a radio station (see “Manual tuning” for
details).
2. Press MEMORY. While the Program Preset
number is still flashing, input your desired
preset number using the numeric buttons, then
press MEMORY to store it.
Retrieving Preset Stations
1. Press TUNER to enter the Tuner mode.
2. Press CH+/ , CH–/ to search up or down for
the preset stations or directly press the numeric
buttons.
iPod does not respond to this unit.
• Remove your iPod from the docking bracket
and check for obstruction on the connectors in
the dock and on your iPod.
• Make sure that your iPod works properly before
docking into the unit. Make sure the software
of iPod is the latest. Please refer to your iPod
manual for details.
I can’t find my file in the jpeg listing.
• Make sure the file name is valid.
The remote control does not work or works
only intermittently.
• Check that batteries are inserted or change
them.
• Aim the remote control at the unit. The infrared
beam must not be blocked or interrupted.
• Check that the remote control is configured
to control the device you are trying to operate
with it.
The subtitles do not appear.
• Check that the DVD disc provides subtitles.
• Refer to the section on how to display sub-
titles.
The disc menu language is not the correct one.
• The disc menu language has not been set up.
• The language of your choice is not available on
the disc.
Night Mode
You can use this function to control the different
sound levels via dynamic compression. It improves
the quality of the sound track at a low volume, and
quiets the loudest sounds.
Use the up/down arrow buttons to highlight the
your preferred choice (Quiet, Moderate or Off) and
press OK.
Channel Delay (Center Delay/ Rear Delay)
Basic settings have been preset for the speakers
included with your unit. However, to suit the
acoustic conditions in your listening room and
to make the sound more effective, you may
need to delay the signal coming from some of
the speakers. Channel delay compensates for
center or surround speakers that are closer to the
listening position than the front speakers.
Use the up/down arrow buttons to adjust the dis-
tance and press OK.
The Setup Menu The Setup Menu Jpeg Files Jpeg Files
5. Press INFO to display the Info menu during play
back. Press INFO twice and select the Play Mode
icon using the left/right arrow buttons. Press
the up/down arrow buttons to select a play
mode (Standard, Repeat Folder, Repeat Disc
and Repeat Track), and press OK.
6. When the unit has played all the files, the slide
show stops and the disc’s contents are dis-
played again.
7. Press STOP to end playback.
Warning: To prevent damage to the unit and/or
your iPod, connect or remove your iPod
when the unit is powered off or the unit
is not in iPod mode.
Caution: Due to the iPod limitation, not all functions
of some iPod models can be controlled via
the remote control of this unit. If necessary,
operate on your iPod directly.
Removing the iPod Dock Adaptor
1. Remove the iPod Dock
Adaptor as shown in the
figure to the right.
-16- -17- -18- -19-
-21- -22- -23- -24-
-26- -27- -28-
-15-
-20-
-25-
The Info Menu
Note:
This function is not available in AUX/
AUDIO IN/TUNER/iPod mode.
5. Press RETURN button to end the photo viewing
and go back to the previous menu.
Using an iPod Classic / iPod Nano to
View Photos
1. In iPod Home menu, use the , button to
select Photos and press the OK button.
“Please Navigate directly on your iPod” will
appear on the screen.
2. Press the , button to select “Photos”, and
then press the OK button to confirm.
3. Press the , , , button to select a photo,
press the OK button to begin playback.
Step 4 Step 3
Step 2-1 Step 2-2
The Setup Menu
Test Tone
This function is used to test and adjust the volume
level (gain) for each individual speaker channel.
Use CH+/ , CH–/ button to select the speaker
channel you wish to test and adjust. You’ll hear
a test tone coming from the speaker you select.
Use the VOL+/- buttons to adjust the level to
your desired setting. Press OK button to exit this
function.
Video Setup
1. Select the Video icon in the main menu using
the left/right arrow buttons.
2. Select a menu option using the up/down arrow
buttons and press OK.
3. Use the up/down arrow buttons to highlight
your preferred choice and press OK.
Slide Time
The Slide Time option lets you select the amount
of time a picture is displayed in a slide show. The
choices are 5 seconds, 10 seconds or 15 seconds.
The unit does not switch on.
• Make sure it is plugged in.
• Press the ON•OFF button on the remote control or
the ON/STANDBY button on the front of the unit.
The device switches off spontaneously.
• The devices switches off automatically when it
is in STOP mode for more than 30 minutes with-
out any user intervention. Switch it on again.
• It might be impossible to read the disc.
• Insert the disc with the printed side facing up.
• Check that the disc can actually be played by
this device.
• Check that the disc’s regional code matches the
unit’s regional code. This unit’s regional code is 1.
• Clean the disc.
There is no picture.
• Check you have switched on the TV set.
• Check the connections.
• Select the AV input assigned to the unit on the
TV.
• Replace the HDMI cable with a better one. A
bad HDMI cable can cause loss of video.
• Press HDMI key on remote control several times
to toggle among different HD OUTPUT.
The picture is of poor quality (with snow or
lines).
• Check the connections.
There is no sound or the sound is of poor quality.
• Check the connections.
• Make sure the speakers are connected.
• Make sure the MUTE function is not on.
No surround sound.
• Check the speaker configuration in the Setup
menu (See Positioning speakers or Audio Set-
up).
Troubleshooting
Precautions
Use
• If your unit has been stored in a cool place
for any length of time, during a journey for
example, wait for about 2 hours before using
it.
• The openings located on the top and bottom
are for ventilation and must not be obstructed.
• During thunderstorms, we recommend that
you isolate the unit from the electrical supply
so that it is not damaged by electrical or
electromagnetic surges.
• This unit is designed for continuous use.
Switching off the unit to standby mode does
not disconnect it from the mains supply. To
completely isolate the equipment, remove the
plug from the mains jack as some components
remain connected to the electrical supply.
• If you notice any burning or smoke, disconnect
the unit immediately to avoid any risk of
electrocution.
• Do not attempt to look inside the unit through
the disk tray opening or any other opening.
You may be electrocuted or exposed to laser
radiation.
• This unit is for domestic use only and must not
be used for industrial purposes.
• Total or partial copying of recordings protected
by copyright legislation, without the explicit
permission of the holder of the rights,
contravenes current legislation. Copying
or downloading music files for sale or any
other business purpose constitutes or could
constitute a violation of copyright law.
Additional Information Limited Warranty
AVC MULTIMEDIA (“AVC”) makes the following limited warranty. This limited warranty extend to the
original consumer purchaser and is limited to non-commercial use of the product.
One Year Parts & Labor Warranty
AVC products purchased in the United States or Canada are warranted to be free from defects in materials
or workmanship for a period of one year from the date of their original retail purchase. If the unit fails
to conform to this warranty, we will service the product using new or refurbished parts and products, at
AVC’s sole discretion.
During a period of one year from the effective warranty date, AVC will provide, when needed, service
labor to repair a manufacturing defect at its designated Service Center. To obtain warranty service in the
United States or Canada, you must first call our Customer Support Center at 1-800-506-5746 or 1-877-
252-6873, during the hours listed in the box below. The determination of service will be made by AVC
Customer Support. PLEASE DO NOT RETURN YOUR UNIT TO AVC WITHOUT PRIOR AUTHORIZATION.
New or remanufactured replacements for defective parts or products will be used for repairs by AVC at its
designated Service Center for one year from the effective warranty date. Such replacement parts or products
are warranted for an additional one year from the date of repair or replacement. The Customer will be
required to ship the unit to the Service Center indicated at the time Customer Support is contacted to make
the necessary repairs. The customer is responsible for all transportation charges to the service facility.
Packaging and Shipping Instruction
When you send the product to the AVC service facility you must use the original carton box and packing
material or an equivalent as designated by AVC.
Your Responsibility
(1) You must retain the original sale receipt to provide proof of purchase.
(2) These warranties are effective only if the product is purchased and operated in the United States or
Canada.
(3) Warranties extend only to defects in material or workmanship, and do not extend to any product or
parts which have been lost or discarded, or damage to product or parts caused by misuse, accident,
improper operation or maintenance, or use in violation of instructions provided with the product,
or to product which has been altered or modified without authorization of AVC, or to products or
parts thereof which have had the serial number removed or changed.
Limited Warranty
Step 3 Step 2
Step 4
Radio
2. Replace it with another one you need.
General Setup
Video
HDMI Setup
TV Type
Default
Player Menu
Audio
Subtitles
Disc Menu
Language Setup
Night Mode
Center Delay
Rear Delay
Test Tone
Audio Setup
Video Setup
Brightness
Contrast
Saturation
Slide Time
4. Press the OK button twice to activate photo
showing to TV screen.
5. Press the RETURN button to end the photo
viewing and go back to the previous menu.
Playing Videos
1. In iPod Home menu, use the , button to
select Videos and press the OK button.
2. Use the , button to select from Movies,
Music Videos, TV Shows, Video Podcasts or
Rentals, press the OK button to enter. (“Please
Navigate directly on your iPod” will appear on
the screen if your are using an iPod touch.)
3. Use the , button to navigate the iPod
menu lists and select a video, press the OK
button to begin playback. (You may also use
the control wheel and keys on your iPod to
operate it.)
• Press the PAUSE button to pause playback,
press the PLAY button to resume playback.
• Press the / button to skip to the previous /
next movie.
• Press the REV/ FWD button to begin fast
reverse/forward, press the PLAY button to
resume normal playback.
4. Press the RETURN button to go back to the
previous menu, then you can select another
video to play.
Note:
Make sure “TV Out” in the setting of
your iPod is set to “On”.
iPod Settings
1. In iPod Home menu, use the , button to
select Settings and press the OK button.
2. Use the , and OK buttons to adjust Shuffle,
Repeat and Language settings.
• Shuffle: Select from Shuffle Off, Shuffle Songs
and Shuffle Albums.
• Repeat: Select from Repeat Off, Repeat One and
Repeat All.
• Language: Select OSD language.
3. Press the RETURN button to go back to the
previous menu.
Please Navigate directly on your iPod
OR
Press The [CLEAR] Key
to go back to main menu
If the above screen appears, you may need to
control the iPod Library directly from your iPod.
Notes:
• Your iPod will be charged automatically
(until fully charged) once it is connected,
no matter whether the unit is in iPod
mode or not.
• Make sure the software of iPod is the
latest.
Playing Music
1. In iPod Home menu, use the , button to select
Music and press the OK button.
2. Use the , button to select from Playlists, Artists,
Albums, Songs, Genres or Composers. Press the OK
button to enter.
3. Use the , button to navigate the iPod menu
lists and select songs, press the OK button to begin
playback. (You may also use the control wheel and
keys on your iPod to operate it.)
• Press the PAUSE button to pause playback, press
the PLAY button to resume playback.
• Press the / button to skip to the previous /
next song.
• Press the REV/ FWD button to begin fast
reverse / forward, press the PLAY button to
resume normal playback.
• Press the REPEAT button to select a repeat play-
back mode (a single repeat or all songs repeat).
Press again repeatedly to cancel this repeat
playback.
3. Touch the “ ” to confirm the photo.
4. Touch the “ Yes ” to activate iPod’s video output.
The photo will appear on the screen.
STS8316Wi English IB for RCA.indd 2 2009-07-15 14:55:09
