8 Connecting Inputs
ˆ
Connecting Inputs
LOW-LEVEL INPUTS
You can connect your auto sound system’s low-level line out jacks to the amplifier’s low-level
line in jacks.
If your auto sound system does not have low-level line out jacks, see “High-Level (Speaker
Wire) Inputs” on Page 9 to connect your amplifier.
Note: For the best results, use shielded audio cables (not supplied) available at your local Ra-
dioShack store.
1. Temporarily place the amplifier as close as possible to the selected mounting location.
2. If your auto sound system has two line out jacks, connect the auto sound system to the
amplifier as shown:
Note: If your auto sound system has four separate line out jacks, use the auto sound sys-
tem’s front left and right jacks to make this connection.
Auto Sound System
Right Left
