PlasmaWall XP-65DHD Owner’s Operating Manual
5
PRE
L
IMINAR
Y
2.1
PlasmaWall at a
Glance
Controls and Indicators
Figure 2-1 shows the PlasmaWall front-panel controls and indicators.
Figure 2-1. PlasmaWall Front-Panel Controls and Indicators
1.
DISPLAY STAND
Optional accessory for table-top installations.
2.
POWER BUTTON
Connects or disconnects the display panel from the AC power source.
3.
STANDBY/ON INDICATOR
- Lights green to indicate normal operation;
- Lights red to indicate that the PlasmaWall is in standby mode.
4.
REMOTE CONTROL SENSOR
Receives the signals from the remote control.
2. Controls and Functions
1
3
2
4
