Raymarine RAY 210VHF User Manual
Page 54
42
DESCRIPTION
Q'ty
Symbol
Parts No.
Resistor 39k ohm
1
R23
Resistor 68k ohm
1
R29
Resistor 100k ohm
5
R21,25,39,62,97
Resistor 150k ohm
1
R27
Resistor 470k ohm
1
R32
IC
IC M3825728GP
1
IC1
IC BR93LC56AF
1
IC2
IC M51951AML
1
IC3
ICTA78L05F
1
IC4
IC LM2092NS
1
IC5
IC NJM386M
1
IC6
Miscellaneous
Switch SKQMAL
15
S1,2,3,4,5,6,7,8,9,10,11,12,13,14,15
Filter ELKF101FA
1
Crystal 4.91MHz
1
X1
ELFC004-BG
1
EL1
LampT-3/4
6
PL1,2,3,4,5,6
Transformer T-7-073
1
L1
LCD TD 624002
1
U1
Connector 52559-3317
1
J1
Connector IL-S-6P-S2T2-EF
1
J4
Connector IL-T-2P-S2C2-W
2
J5,6
