37
SECTION 6
6.1 PARTS LIST
******PF PCB Assembly Section******
DESCRIPTION
Q'ty
Symbol
Parts No.
Capacitor
Ceramic, 15pF (2125)
2
C7,361
Ceramic, 33pF (2125)
2
C4,5
Ceramic, 1000pF (3216)
4
C6,12,18,20
Ceramic, 1000pF
61
C9,21,22,23,24,25,26,27,30,31,32,33,35,36,40,8
0,97,106,107,111,115,118,119,502,121,122,124,
126,127,131,133,134,140,141,143,147,149,151,
170,245,246,250,105,362,363,368,377,378,379,
501,381,383,11,14,16,359,360,336,401,403
Ceramic, 0.5pF
3
C137,402,404
Ceramic, 1pF
1
C109
Ceramic, 2pF
3
C13,108,117
Ceramic, 5pF
4
C123,129,132,139
Ceramic, 6pF
1
C136
Ceramic, 7pF (UJ)
1
C113
Ceramic, 8pF
3
C130,138,145
Ceramic, 10pF
1
C110
Ceramic, 15pF
2
C10.34
Ceramic, 10pF (UJ)
1
C114
Ceramic, 18pF
1
C142
Ceramic, 33pF
4
C28,95,144,146
Ceramic, 27pF
1
C29
Ceramic, 39pF
1
C156
Ceramic, 47pF
1
C37
Ceramic, 51pF
1
C94
Ceramic, 56pF
1
C157
Ceramic, 68pF
1
C104
Ceramic, 91pF
1
C153
Ceramic, 220pF
3
C38,159,160
Ceramic, 6800pF
2
C39.102
Ceramic, 2200pF
2
C41.103
Ceramic, 0.1µF
18
C96,150,152,155,158,161,225,228,232,234,334,
364,365,369,382,343,344,384
Ceramic, 0.01µF
6
C167,168,148,172,407,406
Ceramic, 0.022uF
2
C164.101
Tant., 0.1µF /25V
4
C15,99,226,349
Tant., 1µF/16V
7
C42,98,162,169,227,229,332
Tant., 2.2µF/10V
2
C100.223
Tant., 4.7µF/10V
2
C163,222
Tant., 10µF / 16V
8
C45,154,166,224,231,236,116,385
Elec., 4.7µF/25V
1
C335
Elec., 22µF / 16V
1
C44
Elec., 47µF / 16V
1
C337
