12
» Plasma Remote Control (For Service Use Only)
1 ON/OFF
Switches Power ON/OFF. (This does not operate when POWER/STANDBY indicator of the main unit is off.
2 MENU
Press this button to access the OSD controls.
Press this button during the display of the main menu to go to the sub menu.
3 CURSOR ( / / / )
Use these buttons to select items or settings and to adjust settings or switch the display patterns.
4 LIGHT*
Press this to illuminate the buttons.
* Not available on all models.
5 EXIT
Press this button to exit the OSD controls in the main menu.
Press this button during the display of the sub menu to return to the previous menu.
6 VID 1-2-3
Press this button to select VIDEO as the source.
VID1 VID2 VID3
VIDEO can also be selected using the INPUT SELECT button on the monitor.
7 ASPECT
Press this button to select between aspect ratios.
8 MUTE
Mutes the sound.
9 COMP 1-2
Press this button to select between Component 1 and Component 2 inputs.
10 DISPLAY
Displays the source settings on the screen.
11 VOLUME (+/-)
Adjusts the audio volume.
12 RGB 1-2-3
Press this button to select RGB/PC as the source.
The available sources depend on the setting of “BNC INPUT”.
RGB: RGB1 RGB2 RGB3
COMP: RGB1 RGB3
RGB can also be selected using the INPUT SELECT
button on the monitor.
13 AUTO OFF
Use to select AUTO OFF TIMER settings.
1
3
2
9
8
12
10
7
6
13
5
11
4
Plasma Description
