Roksan Audio ltd Kandy Power Amplifier 2/3 Channel User Manual
CLASSIFICATION: General Use Version 1.0
All specifications are liable to change without notice. E&OE Page 10 of 10 ENGLISH
Inputs Straight (x2 or x3 for3-channel amplifiers)
Trimmed (x2 or x3 for3-channel amplifiers)
Input Impedance 10 k Ω
Input
Sensitivity (115W) 900mV
Outputs Speaker L & R (x1), Speaker Centre (x1 for 3-channel amplifiers)
Output Power >115 Watts, into 8 Ω
>220 Watts, into 4 Ω
Power Supply 500VA Ultra Low Noise Toroidal Transformer
Damping Factor >110 (8 Ω)
Frequency response (-3dB), <3Hz – >100kHz
Straight or untrimmed input
(-2dB), <3Hz –20kHz
Fully trimmed by 7dB
Gain 31.6 dB Straight or untrimmed
24.4 dB Fully trimmed
Harmonic Distortion <0.005% 1kHz - 8 Ω
Signal to Noise Ratio 100dBa (ref. 900mV)
Power Source 100V – 120V 50Hz / 60Hz
220V – 240V 50Hz / 60Hz
Power Consumption Standby <25W, Full Power <800W
Dimension 432 x 380 x 90 (W x D x H) mm
432 x 380 x 102 (including feet)
Weight 14 Kg
Kandy Power Amplifier 2/3 Channel Serial Number: …………………………
Purchase Date Year .……… Month …….. Day ……..
ROKSAN Retailer Name: …………………………………
Location: ………………………………
Please keep a record for future reference
N O T E S K a n d y Power Amplifier 2/3 Channel
S P E C I F I C A T I O N S K a n d y Power Amplifier 2/3 Channel
