6
3. Depending on the distance
between the modular phone jack
and the desired mounting loca-
tion, plug either the supplied 7-
foot or 10-inch silver phone line
cord into the jack on the back of
the phone, then set the phone
aside.
Note: If you are not mounting the
phone directly over the modular phone
jack, press the phone cord into the
groove on the back of the phone so the
cord is flush with the back.
Mounting on Dry Wall/
Sheet Rock
1. Screw a metal anchor into the wall
with a Phillips screwdriver at each
top mark on the template.
2. Using an electric drill, drill a 3 /
16
-
inch hole at each of the bottom
marks.
Paper Template Paper Template
Paper Template
Drill a / hole at each of
the bottom holes
3
16
Drill a / hole at each of
the bottom holes
3
16
Paper Template
Drill a 3 / 16 -inch hole
at each bottom mark
