SECTION 6: H EATER I NSTALLATION
15
FIGURE 16: Linear Heater Layout Overview
g
c
b
d
f
g
c
b
d e
f
g
c
b
d e e
f
g
c
b
d e e e
f
Burner
Reflector
Tube
Tube/Reflector
Hanger
Coupling
Assembly
Vent Adapter
LEGEND
a = 14" (36 cm)
reflector width (not shown)
b = 2" (5 cm)
end cap to burner
c = 2" (5 cm)
end cap to hanger
d = 7'6" (229 cm)
distance first hanger
e = 10' (305 cm)
distance between hangers
f = 9.5" (24 cm)
burner height
g = 17.5" (44 cm)
burner length
10' Tube Length
20' Tube Length
30' Tube Length
40' Tube Length
