4 CH Output Mode
Bridged Dual Mono Output Mode
s p e a k e r c o n n e c t i o n s
4 c h a m p s P L M R A 4 2 0
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS!
4
CH Ster eo Output Mode with Mono Bridged Subwoofer Output
speaker connections
4 ch amp PLMRA420
MINIMUM
SPEAKER
IMPEDANCE
4 OHMS!
SPEAKERS
SUBWOOFER
L
R
PLMRA420
FRONT speakers
REAR speakers
L
R
R
L
speakers
L
R
PLMRA420
