SPECIFICATIONS
– 6 –
MODEL
RHFE-1004FA-P
PROPANE
BTU/h MIN. CLEARANCES
INPUT OUTPUT SIDE TOP
LO:203.4
HI:360.6
LO:203.4
HI:360.5
FRONT
2"
(50mm)
10"
(250mm)
40"
(1m)
40"
(1m)
FAN CFM
OUTPUT
10"
(250mm)
2"
(50mm)
Low
10,500
High
38,400
Low
8,400
High
30,700
Low
8,400
High
29,200
Low
10,500
High
36,500
SPECIFICATIONS
Type of Appliance Fan forced flued gas furnace
Model RHFE-1004FA ENERGYSAVER
Width 36 5/8" (930mm)
Dimensions Depth 12 3/8" with back spacer (315mm with back spacer)
Height 26 3/8" (670mm)
Weight Approx. 90 lbs.
Connections
Electrical AC 120V 60Hz 121 watts
Gas 1/2" female NPT
Combustion System Stainless steel bunsen burner
Ignition System Continuous spark
Operation Finger touch control buttons
Temperature Control
Electronic thermostat HI-LOW/OFF
Up/down switch 2°F increments
Temperature Range
Modulates Continuous
LOW 55°F 60°F 80°F HI High Combustion
Warm Air Outlet Bottom front louver
Indicator/Lamps Operation/Combustion, Filter, SetTemp., RoomTemp., Economy, Function Lock.
Operating Buttons ON/OFF, Up/down, Function-lock, Economy
Economy Mode Energy saving feature
Humidifier Tray Capacity 7 pints (3000cc)
RHFE-1004FA-N
NATURAL
