GETTING TO KNOW YOUR NEW RHFE-1004FA
– 10 –
CONTROL PANEL
OPERATION/TEMPE
RATURE
CONTROL DISPLAY
OPERATION LAMP
RATING PLATE
MODEL NUMBER,
SERIAL NUMBER,
GAS TYPE, ETC.
WARM AIR OUTLET
HUMIDIFIER
OPEN THE DOOR
AND POUR WATER
INTO THE TRAY.
VENT TERMINAL
COMBUSTION/
EXHAUST
COMBUSTION AIR
INTAKE HOSE
EXHAUST PIPE
AIR FILTER
THERMISTOR
GAS CONNECTION
1/2" NPT
POWER CORD
PLUG 120V AC
FILTER LAMP
