Raypak 2600401 User Manual
Page 3
WARNINGS
4
Pay Attention to These Terms
4
GENERAL SAFETY
5
Time/Temperature Relationships in Scalds 5
RECEIVING EQUIPMENT
6
GENERAL
SPECIFICATIONS
6
INSTALLATION
8
Code Requirements
8
Mounting Base
8
Clearances
8
Combustion & Ventilation Air
8
Venting Connections
9
Gas Supply Connections
13
Water Connections & System Piping
14
Electrical Wiring
16
Wiring Diagrams
17
CONTENTS
3
SERVICING PROCEDURES
22
Sequence of Operation
22
Start-up Procedures
22
Controls
26
Repair Section
28
TROUBLESHOOTING
30
Electrical (Electronic Ignition IID)
32
Electrical (Standing Pilot)
33
ADJUSTMENTS & REPLACEMENT
OF COMPONENTS
34
WARRANTY
36
