RIDGID WD1250 - Manual (Page 12)

Key 12 Gallon
No. Part No. Description
1 813213 Toggle Switch
2 820563-4 Screw, Pan Hd. Ty. “AB” 10 x 3/4 Ser.
3 829692 Collector Assembly
4 509488 Float
5 823201-1 Filter Cage
6 826817 Nut, Hex Flange 5/16-18
7 15534-1 Washer
8 818413-2 Blower Wheel
9 818961 Spacer
10 820563-5 Screw, Pan Hd. Ty. “AB” 10 x 1-1/4 Ser.
11 VF4000 Filter
12 73317 Filter Plate
13 73316 Filter Nut
14 825881-2 Drain Cap
15 828833 Caster Foot w/Storage
16 331605 Caster
17 VT2509 Utility Nozzle
18 VT2503 Car Nozzle
19 VT2510 Wet Nozzle
20 VT2508 Extension Wands
21 826356-1 Hose Assembly (Includes Key Nos. 22 thru 24)
22 826355-1 Spring Tab
23 826354 End Hose Interlock
24 815096 Adapter Hose
25 SP6663 Operator’s Manual
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
Repair Parts
12 U.S. Gallons Wet/Dry Vac
Model Number WD12500
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
* Standard Hardware Item - May Be Purchased Locally
† These replacement parts are available where you purchased your vac.
12
*
†
†
†
†
†
*
!
