SSA-324 Specifications
Two-Wire Input
Impedance: 5,000Ω +la%, -20% single ended, 10,000Ω
+100%, -20% differential
Operating Levels: -20 dBu to +0 dBu, nominal
Two-Wire Output
Impedance: 5,000Ω 20% single ended, 10.000Ω 20%
differential
Operating Level: 0.1 mA to 10 mA, nominal
Four-Wire Input
Impedance: 10,000Ω minimum single ended, 20,000Ω
minimum differential operating Levels: -10 dBu to +8
dBu, nominal
Four-Wire Output
Impedance: single ended or differential
Operating Levels: -10 dBu to + 8 dBu, nominal
Transfer Functions (Duck Level set to no ducking)
Voltage Gain, Four-Wire In to Two-Wire Out*
Level Pot 100% rotation: 3 dB
Level Pot 50% rotation: -15 dB 4 dB
Transfer Functions (Duck Level set to no ducking)
Voltage Gain, Two-Wire In to Four-Wire Out**
Level Pot 100% rotation: 22 dB 3 dB
Level Pot 50% rotation: 8 dB 4 dB
Frequency Response (Reference: 1 kHz, 0 dBu input)
Four-Wire Input to Two-Wire Output: 200 Hz to 5 kHz,
+1,-4 dB, typical
Two-Wire Input to Four Wire Output: 250 Hz to 5 kHz,
+1, -4 dB, typical
Signal-to-Noise Ratio (Reference: 1 kHz, 0 dBu at two-
wire)
Two-Wire to Four-Wire: -60 dB
Four-Wire to Two-Wire: -60 dB
Crosstalk (Reference: 1 kHz, 0 dBu)
System A to System B,
Two-wire to Two wire
200 Hz to 5 kHz: -50 dB,
Environmental
Temperature
Operating: 0.0 to 50” Celsius
Storage: -40” to 85” Celsius
Humidity: 0 to 95%. non-condensing
Mains Voltage
Standard: 120 volts 10%, 50-60 Hz
*P Option: 230 volts 10%, 50-60 Hz
#D Option: 100 volts + 10%. -5%, 50-60 Hz
Mains Amperes
Standard: 0.20A @ 120 volts 10%, 50-60 Hz
*P Option: 0.10A @ 230 volts 10%. 50-60 Hz
#D Option: 0.22A @ 100 volts +10%,.-5%. 50-60 Hz
Dimensions
1.72” ( 44mm) high, 8.19” (208mm) wide, 8.00”
(204mm) deep
Weight
SSA-324: 2.75 lbs (1.3 kg)
MCP-1: 1.0 lbs (0.45 kg)
MCP-2: 1.0 lbs (0.45 kg)
Finish
Thermoplastic front panel, aluminum case, light gray
finish.
Nulling:
Manual
Ordering Information
SSA-324
System-to-System Interface
Catalog Number: 9000697900
SSA-324#U
System-to-System Interface
Catalog Number: 9000697921
This specifications information is preliminary and is subject to change without notification.
Brand names mentioned are the property of their respective companies.
Contact Information
Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, Minnesota 55337
Telephone: 877·863·4169
Fax: 800·955·6831
Form Number: LIT000031000
Date: April, 2006
