X-2 ADD-ON KIT
For Zone 4 above-ground installations
X-1 RACK KIT
Standard rack kit for ground-level installations
Kit contains all assembly hardware.
X-2 ADD-ON LEG
For submittal information, see Catalog No. 1000.92
S
URE
R
ACK
K
IT
® TM
Hi Delta
Models
X-1
Part
Number
X-2
Part
Number
A B C
302 006906
007046
30 41-1/4 72-1/4
402 006907 30 48-1/4 72-1/4
502 006908 30 55-1/4 72-1/4
652 006909 30 65-3/4 72-1/4
752 006910 30 72-3/4 72-1/4
902 006911 30 83-1/4 72-1/4
992 011536
007053
37-1/2 64-1/8 87-1/2
1262 011564 37-1/2 75-1/2 87-1/2
1532 011565 37-1/2 87 87-1/2
1802 011566 37-1/2 98-1/8 87-1/2
2002 011567 37-1/2 109-1/2 87-1/2
2072 011567 37-1/2 109-1/2 87-1/2
2342 011568 37-1/2 121 87-1/2
SEISMIC INFORMATION
Hi Delta
Model
Seismic Zone 3 Seismic Zone 4
Ground
Level
Above
Ground
Ground
Level
Above
Ground
302 thru 902 Standard X-1 Kit Standard X-1 Kit Add X-2 Kit
992 thru 2342 Standard X-1 Kit Add X-2 Kit
B
A
C
