Pecifications – Rockford Fosgate 50.1 User Manual
Page 50
Dynamic Power Rating (IHF-202 Standard) - Measured at 14.4V
Mono into a 4
Ω
load
100 Watts
Mono into a 2
Ω
load
200 Watts
Mono into a 1
Ω
load
325 Watts
2-channel Bridged (using 2 Punch 50.
1
) into a 2
Ω
load
650 Watts
Continuous Power Rating (Competition Standard) – Measured at 13.8 Volts
RMS continuous power mono, into a 4
Ω
load from 20-20,000Hz
with less than 0.05% THD
50 Watts
RMS continuous power mono, into a 2
Ω
load from 20-20,000Hz
with less than 0.10% THD
100 Watts
RMS continuous power mono, into a 1
Ω
load from 20-20,000Hz
with less than 0.3% THD
200 Watts
RMS continuous power bridged, (using 2 Punch 50.
1
Power amplifiers in the same system) into a 2
Ω
load
from 20-20,000Hz with less than 0.3% THD
400 Watts
Signal-to-Noise Ratio:
>100dB (A-weighted)
Frequency Response:
20Hz-20,000Hz
±
0.5dB
Bandwidth:
10Hz–250kHz
±
3dB
Damping Factor @ 4
Ω
(at output connector):
>200
Slew Rate:
50V ms
IM Distortion (IHF):
<0.05%
Input Impedance:
20k Ohms
Source Unit Compatiblity (+15dB gain overlap):
28V max. input
Input Sensitivity (+0dB gain overlap):
Variable from 300mV to 5V
Pass-Thru Output:
Unity Gain
B+ Fuse Size: (External to amplifier)
40 Amp or two 20 Amp
Fuse Type:
AGU
Crossover Slope:
12dB or 24dB/octave Butterworth
Factory Crossover Frequency:
80Hz (0.047mf)
Factory Default Crossover Setting:
Full Range
Dimensions:
9-5/8"W x 13-9/32"L x 2-5/8"H
(24.4cm) x (33.73cm) x (6.6cm)
50.
1
S
PECIFICATIONS
– 47 –
Specifications subject to change without notice.
