Radio Shack 22-1670 - Manual (Page 10)

10
Windshield Mounting
The supplied suction-cup mount lets you mount the
detector on the windshield.
Caution: Do not use the suction-cup mount in a vehicle
that has a plastic coating on the windshield designed to
protect passengers during an accident. If you use the
suction-cup mount on this type of windshield, you might
permanently mar the windshield’s surface.
1. Remove the cover by pressing its raised dots and
pushing out. Store the cover in a safe place.
2. Align the groove in each suction cup with the slots in
the bracket and slide the suction cups out until they
lock into place. Then press the rubber cushions
onto the metal tips. Finally, screw the base plate
onto the bracket through the threaded dowel, but do
not tighten the screw.
Threaded
Dowel
Suction
Cups
Rubber
Cushions
Bracket
Base Plate
Screw
22-1670.fm Page 10 Friday, August 6, 1999 10:17 AM
