Raymarine Pathfinder Radar Scanner User Manual
Page 48
20
Pathfinder Radar Scanners
Table 1-9: Max. Extension Power Cable Lengths (m), 24 V Systems -
10 kW Scanners
Inter-Unit Cable(s)
Power Cable Core (each core)
mm
2
:
AWG:
1.5
16
2.0
15
2.5
14
4.0
11
5 m Heavy
12.0
16.0
20.0
32.0
10 m Heavy
10.5
14.0
18.0
28.0
15 m Heavy
9.0
12.0
16.0
24.0
15 m Heavy + 5 m ext
7.5
10.0
13.0
20.0
15 m Heavy + 10 m ext
6.0
8.0
10.0
16.0
25 m Heavy
6.0
8.0
10.0
16.0
25 m Heavy + 5 m ext
4.5
6.0
8.0
12.0
25 m Heavy + 10 m ext.
3.0
4.0
5.0
8.0
Table 1-10: Max. Extension Power Cable Lengths (m), 32 V Systems -
10 kW Scanners
Power Cable Core Size (each core)
mm
2
:
AWG:
1.5
16
2.0
15
2.5
14
10 kW Scanners
≤15.0
≤20.0
≤25.0
